Vacuum Laboratory Tube Furnace for Production Applications
Sentro Tech’s 1600°C vacuum tube furnace is ideal for applications requiring high or prolonged temperatures. Our standard model 1600°C Horizontal Tube Furnace, STT-1600C, comes with a set of standard features and elements. Or customize standard features and elements, from sizing to tube type, to create an industrial furnace to suit your application.
Request a quote today on a 1600°C vacuum laboratory tube furnace.
STT-1600°C (2910°F) Vacuum Tube Furnace Features
- 30-segment easy use PID programmable temperature controller
- Industrial grade MOSi2 heating elements
- High efficiency ceramic fiber insulation
- Heat isolating ceramic tube
- Long life B-type thermocouple
- Stainless steel sealing plate
- Worm gear clamp
- Set of fasteners
- Vacuum and process gas connection nozzle
- One-year limited warranty on all electronic parts
- Standard High Alumina Tube Size: 1.5″, 2.0″, 2.5″, 3.0″ and 3.5″
- SiC, Stainless, or Quartz Tube Sizes: 1.5″, 2.0″, 2.5″, 3.0″, 3.5″, 4.0″ , 6.0″ and 8.0″
- Standard Heating Zone Lengths: 6″, 12″, 18″, 24″, and 36″
- Custom heating zone length up to 48” is available, as well as multi-zone furnaces with independent controller systems.
Find Your Vacuum Laboratory Tube Furnace
Contact Sentro Tech today and speak with one of our representatives to learn more about which vacuum laboratory tube furnace is right for your application.
Browse STT-1600°C (2910°F) Vacuum Tube Furnace Models
| MODEL | Tube Heat Zone | Outside Dimensions | Temperature (°C) | Power (KW) | Amps | Volts |
|---|---|---|---|---|---|---|
 STT-1600°C-4 |
4 | 23″ H x 16″ W x 18″ D | 1600° C | 3 | 20A | 208/240V 1-Phase |
| STT-1600°C-6 |
6 | 28″ x 19″ x 19″ | 1600° C | 4 | 25A | 208/240V 1-Phase |
| STT-1600°C-12 |
12 | 28″ x 41″ x 21″ | 1600° C | 7 | 40A | 208/240V 1-Phase |
| STT-1600°C-24 |
24 | 1600° C | 208/240V 1-Phase |
Frequently Asked Questions
What is a 1600°C vacuum tube furnace used for?
SentroTech’s 1600°C (2910°F) vacuum laboratory tube furnace is ideal for laboratory and small-scale production applications requiring high or prolonged temperatures. With a full suite of standard features and fully customizable sizing and tube configurations, it can be tailored to suit a wide range of application requirements.
What tube types and sizes are available for the STT-1600°C vacuum tube furnace?
The STT-1600°C vacuum laboratory tube furnace is available with standard High Alumina tube sizes of 1.5″, 2.0″, 2.5″, 3.0″, and 3.5″. SiC, stainless steel, and quartz tube options are also available in sizes ranging from 1.5″ up to 8.0″. Standard heating zone lengths run from 6″ to 36″, with custom lengths up to 48″ available upon request.
Can the STT-1600°C vacuum tube furnace be configured for multi-zone heating?
Yes. SentroTech’s 1600°C vacuum laboratory tube furnace is available in multi-zone configurations with independent controller systems, allowing for more precise and complex thermal processing across different zones within a single furnace setup. Custom heating zone lengths up to 48″ are also available.
What standard features does the STT-1600°C vacuum tube furnace include?
The STT-1600°C vacuum tube furnace comes standard with a 30-segment PID programmable temperature controller, industrial-grade MoSi2 heating elements, high-efficiency ceramic fiber insulation, a long-life B-type thermocouple, a stainless steel sealing plate, a worm gear clamp, a set of fasteners, and a vacuum and process gas connection nozzle. All models include a one-year limited warranty on all electronic parts.
Can the STT-1600°C vacuum laboratory tube furnace be customized?
Yes. SentroTech’s 1600°C vacuum laboratory tube furnace is fully customizable from sizing and tube type to heating zone length and multi-zone configurations. Whether your application requires a specific tube material such as SiC, stainless steel, or quartz, or a custom chamber size, SentroTech representatives are available to help configure the right vacuum tube furnace for your needs.
