1300° C (2370°F) Atmospheric Vacuum Furnace

All-in-One Controlled-Atmosphere & Vacuum Furnace

Sentro Tech’s 1300°C Vacuum and controlled atmosphere furnace versatile high temperature furnaces facilitate operation of firing cycles where atmosphere condition can be altered during operation cycle, from oxidizing, (such as air to inert atmosphere), or argon/nitrogen to vacuum. This type of vacuum furnace makes multi-atmosphere process in one cycle possible: binder burn out in air and parts sintering under vacuum or inert gas atmosphere. These atmosphere furnaces are designed for accurate air/inert gas flow rate control, accurate temperature control, excellent temperature uniformity, long lasting performance and safe operations. This vacuum atmosphere furnace is ideal for vacuum atmosphere brazing, sintering, surface treatment, thermal heat treatment and high temperature material process including stainless steel, titanium, aerospace material, silicon carbide wafer, other metals and ceramics.

Price Out Your New Vacuum Furnace

STV-1300°C Vacuum Furnace Features

  • Max working temperature: 1300°C in vacuum, inert atmosphere and air.
  • 208/220V single phase for all models except STV-1300°C-181818, STV-1300°C-242424 & STV-1300°C-363636 (STV-1300°C-181818& STV-1300°C-242424 require three phases)
  • Max vacuum: 10-2 torr
  • Excellent temperature uniformity
  • 30 Segment Easy Use PID Programmable Temperature Controller, allows the control of heating rates, dwells (time holds) and cooling rates
  • Silicon carbide heating elements are designed in a unique U shaped configuration to ensure the longest heating element life, best heat radiation properties at high temperature and easy exchange
  • All models use Ceramic fiber board lining to ensure energy efficiency
  • All models use Long Life Platinum/Rhodium S Type Thermocouple
  • One Year Limited Warranty on All Electronic Part
  • Most models are in stock for quick delivery
  • Custom sizes available on reques

Browse STV-1300°C Atmospheric Furnace Models

Model Chamber H x W x D Outside Dimensions Temperature (c) Power (KW) Amps Volts
Model: STV-1300°C-666 Chamber H x W x D: 6"x6"x6" Outside Dimensions: 40"x30"x52" Temperature: 1300°C Power (KW): 4 Amps: 25A Volts: 208/240V 1-Phase
Model:
STV-1300°C-888
Chamber H x W x D: 8"x8"x8" Outside Dimensions: 44"x33"x58" Temperature: 1300°C Power (KW): 6 Amps: 40A Volts: 208/240V 1-Phase
Model: STV-1300°C-101012 Chamber H x W x D: 10"x10"x12" Outside Dimensions: 49"x37"x66" Temperature: 1300°C Power (KW): 9 Amps: 50A Volts: 208/240V 1-Phase
Model: STV-1300°C-121216 Chamber H x W x D: 12"x12"x16" Outside Dimensions: 55"x41"x75" Temperature: 1300°C Power (KW): 16 Amps: 90A Volts: 208/240V 1-Phase
Model:
STV-1300°C-181818
Chamber H x W x D: 18"x18"x18" Outside Dimensions: 81"x52"x95" Temperature: 1300°C Power (KW): 30 Amps: 90A Volts: 208/240V 3-Phase
Model: STV-1300°C-242424 Chamber H x W x D: 24"x24"x24" Outside Dimensions: 96"xx9565" Temperature: 1300°C Power (KW): 50 Amps: 150A Volts: 208/240V 3-Phase
